TA-15 SY 640
CNC turning center with
counterspindle +Y
TA-15 SY 640
Max. diameter of machined rod 50mm
Max diameter of machined flange 220mm
Y axis with travel 70 -50mm ¨
Counterspindel
Rotary tools max.12000rpm,
ER32, internal cooling
Machine produced by CMZ Spain.
.
CNC LATHE
GT 250
Producer YCM
maximum 52 mm diameter machined rod
maximum diameter of the flange 250 mm
.
CNC lathes
center axis "Y"
L 200Y FANUC
Producer Hyundai
maximum 65 mm diameter machined rod
335 mm maximum diameter of the flange
maximum machining length 455 mm
Y-axis with travel - 50 mm +
automatic tailstock
Rotary tools in 12 positions, max. 5000ot / min., clamping ER32
.
Micro-
marking equipment
P5000Z EM
rotary axis for stamping on the perimeter,
stamping work. space 100x100mm
.
profile projector
STARRETT
HE 400
Software ML210 - METLOGIX M2 - 2D
Automatic calculation of geometric elements
and their relationships
Automatic storage of measured results
Graphic display of measured elements
Graphical representation of geometric calculations solved
Converting units mm / inch
Calculating deviations of shape
Tolerance and evaluation of deviations
.
